ThermaForge TitanPro 120 Greenhouse Heater

The ThermaForge TitanPro 120 Greenhouse Heater is engineered for commercial growers who require precise, reliable heat in demanding climates. This condensing, modulating unit features a stainless heat exchanger, insulated steel cabinet, and variable-speed EC blowers that deliver plant-safe, even warmth through duct collars on each side. With sealed combustion and smart controls, it maintains optimal temperature and humidity while minimizing fuel use and emissions.

Specifications

• Material: Powder-coated galvanized steel cabinet, 316L stainless-steel heat exchanger, insulated service panels

• Dimensions: 140 cm (L) x 110 cm (W) x 130 cm (H)

• Features: Modulating 20–100%, sealed combustion, low-NOx burner, dual 250 mm duct collars, touchscreen controller

• Heat Output: 120 kW (≈409,000 BTU/h) with 92–97% thermal efficiency

• Coverage Area: Up to 1,100 m² (≈12,000 ft²) depending on climate and glazing

Features

• Condensing Stainless Exchanger: Recovers latent heat for lower fuel consumption and drier interiors

• Sealed Combustion & Filtration: Plant-safe air quality with outside combustion and serviceable intake filter

• EC Variable Blowers: Quiet, efficient airflow matched to setpoint and load

• Smart Grow Control: Scheduling, staging, and remote monitoring via BACnet/Modbus or optional app gateway

• All-Season Durability: Insulated panels, corrosion-resistant hardware, and weather-sealed electronics

• Rapid Installation: Pallet-ready base, quick-connect gas/electric, and pre-drilled mounting points

Maintenance

• Daily: Verify unobstructed intake and discharge; check for normal operating lights

• Weekly: Inspect filters and condensate drain; wipe dust from service panels and vents

• Annually: Schedule certified service to clean exchanger, test gas pressure, and update controller firmware

Warranty

• Heat Exchanger & Cabinet: 7 years

• Electronics & Blowers: 3 years
